LS1212E
Electric Scissor
Lift E-Drive
Secure and Reliable
- Complied with GB/CE/ANSI and other standards;The main structural components are welded and electrophoretic automatically, which are rust resistant and durable;Standard height limit anti-collision rods for safer operation.
Intelligent and Efficient
- Automatic display of fault codes for quick troubleshooting; -Proportional decrease control, smooth and flexible operation; Large ground clearance, maximum gradeability 25%; Intelligent interconnection, real-time monitoring of working condition data.
Better Total Cost of Ownership
- The generalization rate of parts and accessories reaches 95%, and few categories of spare parts need to reserve;Maintenance-free AC motors; Low power alarm and other machine control systems+lithium battery management system (BMS), improving the life of battery.
Max.Work Height
14 m
Overall Length/Width
2.49 * 1.19 m
Battery
24 V / 225 Ah
Overall Lift Capacity Max.
320 kg
Specification
Download a brochureLS1212E
Max.Working Height
14 m
Max.Platform Height
12 m
Min.Platform Height
2.28 m
Platform Size（L×W）
2.28 * 1.15 m
Overall Lift Capacity Max.
320 kg
Max. Platform Occupants
2
Gradeability
25%
Tilt Sensor Activation
X1.5° / Y3°
Overall Weight
3040 kg
Battery
24 V / 225 Ah
Lift Motor
24 V / 3.3 kW
